How to Check Engine Oil Level

Step 1: Prepare Your Vehicle

For an accurate oil level reading, your vehicle should be prepared properly:

• Park your car on level ground
• Turn off the engine and wait at least 10 minutes for the oil to drain back into the oil pan (some manufacturers recommend checking when the engine is cold, while others when it's warm - check your owner's manual)
• Open the bonnet and secure it properly

Step 2: Locate the Dipstick

The oil dipstick typically has a brightly colored handle (often yellow, orange, or red) and is usually labeled "Engine Oil." In most vehicles, it's located near the front or side of the engine. If you're having trouble finding it, consult your owner's manual.

Step 3: Remove and Wipe the Dipstick

Now it's time to check the oil level:

1. Pull out the dipstick: Pull the dipstick all the way out of the tube. Be careful not to drip oil.
2. Wipe it clean: Use your clean cloth or paper towel to wipe all oil from the dipstick. This ensures you'll get an accurate reading.

Step 4: Reinsert and Check the Level

1. Reinsert the dipstick: Push the dipstick all the way back into its tube, ensuring it's fully seated.
2. Pull it out again: Remove the dipstick once more and hold it horizontally.
3. Check the oil level: Look at both sides of the dipstick. The oil will leave a mark showing how high the oil level reaches.
4. Read the indicators: Most dipsticks have two marks or holes indicating the minimum and maximum oil levels. The oil level should be between these two marks.

Step 5: Assess the Oil Condition

While checking the level, also assess the condition of the oil:

• Color: Fresh oil is amber or light brown. Dark brown or black oil indicates it's time for an oil change.
• Consistency: Oil should be smooth and slightly translucent. If it's gritty, very thick, or has visible particles, it needs changing.
• Smell: Oil shouldn't have a burnt smell. If it does, it could indicate engine problems.

Step 6: Add Oil If Necessary

If the oil level is below or near the minimum mark, you'll need to add oil:

1. Locate the oil filler cap: This is usually on top of the engine, labeled "Oil" or with an oil can icon.
2. Add oil gradually: Remove the cap and use a funnel to add small amounts of oil at a time (about 1/4 litre or 250ml).
3. Use the correct oil type: Check your owner's manual for the recommended oil viscosity (e.g., 5W-30, 10W-40) and specification.
4. Recheck the level: After adding oil, wait a minute for it to drain down, then check the level again using the dipstick.
5. Repeat if necessary: Continue adding small amounts until the level is near (but not above) the maximum mark.

Step 7: Finish Up

1. Replace the dipstick: Make sure it's fully inserted.
2. Close the oil filler cap: If you added oil, ensure the cap is tightly secured.
3. Clean up: Wipe away any spilled oil and dispose of oily rags properly.
4. Close the bonnet: Make sure it's securely latched.

Oil Level Too Low

If your oil level is consistently low, it could indicate:

• An oil leak (look for spots under your parked car)
• Oil burning in the engine (blue smoke from exhaust)
• An aging engine that's consuming more oil

Action: Add oil to bring it to the proper level, but have your vehicle checked by a professional if the issue persists.

Oil Level Too High

If the oil level is above the maximum mark, it could be due to:

• Overfilling during an oil change
• Fuel dilution (fuel mixing with the oil)
• Coolant leaking into the oil (which may make it look milky)

Action: If significantly overfilled, have excess oil drained by a professional. Driving with too much oil can damage your engine.

Milky or Frothy Oil

Oil that looks milky, frothy, or like a milkshake indicates:

• Coolant is leaking into the oil (possible head gasket issue)
• Condensation buildup (often from short trips in cold weather)

Action: This requires immediate professional attention. Stop driving the vehicle if possible.
